Production Information

Gravity Induction Timer (charging version)

44 x 44 x 46mm

ABS

Product Parameters

Battery capacity: 500mAh

Working temperature: 0 ° C-50 ° C

Standard power consumption:<20uA

Sleep power consumption: ＜ 150uA

Working current: 11mA

Charging current: 500mA

Volume range: Mute/vibrate, 90~100dB loud, 70~80dB low

Product Operation Instructions

Gravity Mode: Turn the button to mode 1: Flip 5-10-30-60 minutes upwards to automatically start the countdown. The screen will flip upwards and pause, while the opposite screen will clear to zero for timing downwards.

Manual Mode: Move the button to mode 2: Adjustable M/S button, press the middle button ST/SP to start the countdown.

Timing:

1.When the display is 00:00, short press the [SP/ST] key to start the countdown.

2.During the timing process, short press the [SP/ST] button to pause/start the countdown;

3. In a paused state, long press the [ST/SP] key to reset to zero.

Countdown setting:

1. Short press the [M/S] key to gradually increase the countdown time, long press the [M/S] key to quickly increase the countdown time. After setting, short press the [SP/ST] key to start the countdown;

During the timing process, short press the [SP/ST] button to pause/start the countdown;

3. In a paused state, long press the [SP/ST] key to reset to zero;

4. After the countdown time reaches 00:00, there will be a one minute long alarm clock (the "Didi Di" LED screen will light up/the sound will stop, and the LED screen will turn off - these two prompts are grouped in a 1-second cycle - to remind you).

Silent mode vibration reminder.

5. Memory mode: After the countdown ends, briefly press the [SP/ST] button again to display the current set time. To reset to zero, press and hold the ST/SP button. Short press to cycle through the operation again.

Matters Needing Attention:

If the user forgets to turn off the device, or if there is no action after 5 minutes, the product will automatically go to sleep;

2. After the countdown ends, the alarm duration is 1 minute;

3. After hibernation, if the shutdown gravity mode is not toggled, it can be flipped and used immediately. The manual mode can be adjusted with just one press;

In silent mode, there is vibration feedback at the end of the timer or any operation. There is a "beep" feedback during operation in volume mode;

5. If the battery level is below 10%, the screen will flash, reminding to charge. The charging process will light up with a red light, while the fully charged green light will remain on.
